PXT-K-30V30: Vacuum/Pressure Transmitter, 4-20 ma, 0.25% accuracy, -30" Hg./+30 psig.  CSA certified.  (05707731)

The PXT-K-30V30 Vacuum and Pressure Transmitter is a state-of-the-art instrument providing a 4 to 20 mA output and -30" Hg./+30 psig. It features a precision micro-machined silicon diaphragm with a fully welded stainless steel pressure port for greater accuracy, stability and a wide range of compatibility.

Silicon technology is used to provide a miniature micro-machined diaphragm which is electrostatically bonded to a glass substrate and is then stitch-bonded within a glass to metal seal assembly to provide exceptional thermal and stress isolation. This technology assures you of high accuracy and stability over a wide range of operating conditions. The corrosion resistant enclosure is made of 316 stainless steel and all wetted parts are 316L stainless steel or HASTELLOY C276.

The PXT-K-30V30 can be used in applications such as compressors, engines, process control, liquid level and pumps. Accuracy is rated at +/- 0.25% including non-linearity, hysteresis and repeatability. Long term stability better than 0.2% FS over twelve (12) months. Process connection is 1/4 NPT female.

Features:
•  Process Connection: 1/4 NPT female with 7/8" Hex Nut
•  Electrical Connection (PXT-K-30V30): 1/2” NPT Male Conduit connection with 60" long cable, vented
•  Wetted Parts: 316L Stainless Steel or HASTELLOY C276 to comply with NACE MR0175
•  Supply Voltage: 8-30 VDC (Typically 24 VDC)
•  CSA (c/us): Class I / II / III, Div 1 , Groups A-F T4
•  Class I / II / III, Div 2, Groups A-D,F,G T4
